CO2 LASER Cutting & Engraving Machine
Key Features
- Precision Laser: CO2 sealed tube (60W–180W) for accurate cutting/engraving.
- Work Area Options: 900×600 mm, 1300×900 mm, or 1400×1000 mm.
- High Speed: Up to 6000 cm/min engraving, 5000 cm/min cutting.
- Durable Components: Leadshine motor, Yuming motion, brass pulleys.
- Cooling & Safety: CW-5000/CW-5200 chiller, air compressor & Exhaust Blower for fume control.
- Software Support: CorelDraw, Photoshop, AutoCAD; formats: BMP, PLT, DST, DXF, AI.
- Bed Types: Honeycomb or Aluminium Strip bed.
Technical Specification
| PRODUCT OVERVIEW | |
|---|---|
| Model | LASER Cutting & Engraving Machine |
| Working Area | 900x600 / 1300x900 / 1400x1000 |
| Bed Type | Honeycomb / Aluminium Strip Bed |
| Laser Power | 60W, 80W, 100W, 130W, 150W, 180W |
| LASER Tube | EFR (Optional Yongli / Reci) |
| LASER Type | CO2 sealed laser tube, water-cooled (Glass Tube) |
| Engraving Speed | 0–6000 cm/min |
| Cutting Speed | 0–5000 cm/min |
| Motor & Drive | Leadshine |
| Driving System | Stepper Motor |
| Motion System | Inner Slide Guide Rails |
| Pulley Material | All Brass |
| Chiller | CW-5000 / CW-5200 |
| Blower | 550W / 750W |
| Air Compressor | 135W / 160W |
| Graphic Format Supported | BMP, PLT, DST, DXF, AI |
| Software Supported | CorelDraw, PhotoShop, AutoCAD, TAJIMA |
| Power Supply | 220V/50HZ, 110V/60HZ |
| Optional Parts | Up-down Worktable, Rotary Axis |
| Applicable Material | Acrylic, Crystal, Glass, Ceramic, Marble, Metal Coating, Cloth, Fabric, Wood etc. |
